تصنيف الضغط: 85 ~ 232psig (PN6 ~ PN16)
حجم الاتصال (مم)
|
size |
L |
Valve size |
||||
|
Valve diameter |
Pair clamp type |
Lug |
Double flange type |
A |
B |
|
|
In |
mm |
mm |
mm |
mm |
mm |
|
|
2 |
50 |
43 |
106 |
185 |
93 |
|
|
2-1/2 |
65 |
46 |
112 |
199 |
102 |
|
|
3 |
80 |
46 |
114 |
205 |
108 |
|
|
4 |
100 |
52 |
127 |
224 |
127 |
|
|
5 |
125 |
56 |
140 |
237 |
139 |
|
|
6 |
150 |
56 |
140 |
250 |
151 |
|
|
8 |
200 |
60 |
152 |
291 |
195 |
|
|
10 |
250 |
68 |
165 |
336 |
228 |
|
|
12 |
300 |
78 |
178 |
383 |
270 |
|
|
14 |
350 |
78 |
190 |
411 |
285 |
|
|
16 |
400 |
102 |
216 |
450 |
322 |
|
|
18 |
450 |
114 |
222 |
470 |
339 |
|
|
20 |
500 |
127 |
229 |
528 |
380 |
|
|
24 |
600 |
154 |
267 |
613 |
465 |
|
|
28 |
700 |
165 |
292 |
740 |
491 |
|
|
32 |
800 |
190 |
318 |
835 |
588 |
|
|
36 |
900 |
200 |
330 |
845 |
640 |
|
|
40 |
1000 |
216 |
410 |
940 |
740 |
|
